| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 200 | 220 |
| Power Rating (kW) | 160 | 176 |
| Frequency (Hz) | 50 | |
| Engine Model | 6CTAA8.3-G12 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (Customizable) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BC220 (Open Type) | BC220S (Silent Type) |
|---|---|---|
| Length (L) mm | 2570 | 3400 |
| Width (W) mm | 950 | 1220 |
| Height (H) mm | 1850 | 1780 |
| Tank Capacity (L) | 368 | 368 |
| Engine Model & Manufacturer | 6CTAA8.3-G12 (Cummins) |
| Number of Cylinders | 6 |
| Cylinder Arrangement | In-line |
| Cycle | Four Stroke |
| Aspiration | Turbocharged and Charge Air Cooled |
| Bore x Stroke | 114 x 135 mm |
| Displacement | 8.3 L |
| Compression Ratio | 18.0:1 |
| Prime Power/Speed | 183 kW/1500 rpm |
| Standby Power/Speed | 203 kW/1500 rpm |
| Alternator Brand | BOBIG |
| Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-274H |
| Rated Power | 160kW/200kVA |
| Rated Voltage | 230V/400V |
| Rated Frequency | 50Hz |
| Protection Grade | IP23 |
| Insulation Class | H Class |
